TT-JAX ( .173" ) CONNECTORIZED JACKFIELDS – PART NUMBERS
JACK PANELS
?
FAX: 773 792-2129
* Please visit the product pages on our website for the most up-to-date product information
TT-JAX ? (.173") CONNECTORIZED JACKFIELDS (continued)
PART NUMBERS
223
1. Compose part numbers from data below to specify your
jackfield...or use the table to order popular jackfields.
SPECIFYING NOTE: Any jackfield can be manufactured
with AMP CHAMP connectors. Contact Switchcraft.
T
T
2
W
2
4
V
C
F
1
UNIT TYPE
NUMBER OF
RACK MOUNTING
JACK TYPE
TT - .173"
JP - LONG FRAME (1/4")
2W - 2 WIRE
4W - 4 WIRE
6W - 6 WIRE
CIRCUITS
12
24
48
96
1 - 19 inch
2 - 23 inch
TYPE OF HINGE
F - FRONT PANEL HINGED
R - REAR PANEL HINGED
MONITOR JACK
V - WITHOUT
M - WITH
WIRE TERMINATION
N - NON-HINGED
C - AMPHENOL BLUE RIBBON
B - AMP CHAMP
W - TERMINAL BLOCK
TYPICAL PART NUMBERS
2-WIRE JACKFIELDS
Part Number
TT2W48VCF1
TT2W48VCN1
TT2W48MCF1
TT2W48MCN1
4-WIRE JACKFIELDS
Part Number
TT4W24MCF1
TT4W24MCN1
TT4W24VCF1
TT4W24VCN1
6-WIRE JACKFIELDS
Part Number
TT6W48MCF1
16J1055
TT6W48MCN1
TT6W48VCF1
TT6W48VCN1
Description
Hinged front panel.
Front panel NOT hinged.
Same as TT2W48VCF1, except with MONITOR jack row.
Same as TT2W48VCN1, except with MONITOR jack row.
Description
Hinged front panel with MONITOR jack row.
Front panel NOT hinged with MONITOR jack row.
Same as TT4W24MCF1, except no MONITOR jack row.
Same as TT4W24MCN1, except no MONITOR jack row.
Description
Hinged front panel with MONITOR jack row.
Hinged front panel with MONITOR jack row.
Front panel NOT hinged with MONITOR jack row.
Same as TT6W48MCF1, except no MONITOR jack row.
Same as TT6W48MCN1, except no MONITOR jack row.
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
